*Rugged sealed construction;
*Cylindrical design, easy for installation;
*Short-range measurement capabilities
Application:
ultrasonic gas flow meter, wind speed and direction, distance ranging etc
Technical parameter:
Construction: rugged sealed
Center Frequency: 200KHz ± 5%
Mini. Resistance: 360Ω ± 20%
Capacitance: 650pF ± 20% @1KHz
Sensitivity: Ehco signal 25mV(-62dB) @0.3m, 800Vpp
Max. Input Voltage: less than 1000Vpp
Working temperature: -40~+80℃
Pressure: ≤3Kg or 0.3MPa
Angle: (beam width) Half-power angle@-3dB: 7°±10%, Sharp Angle: 17°±10%
Detectable range: 0.10 ~ 1.5m
Protection Class: IP68
Housing Material: titanium alloy
Gross weight: 8g ± 5%
Wiring instructions: ‘+’ red, ‘-’ white, black: shielded cable
For more details, please contact us.
