*Rugged sealed construction;
*Cylindrical design, easy for installation;
*Short-range measurement capabilities
Application:
Urea test, ultrasonic gas flow meter, wind speed and direction, distance ranging etc
Technical parameter:
Construction: rugged sealed
Center Frequency: 2MHz ± 5%
Mini. Resistance: 20Ω ± 20%
Capacitance: 1900pF ± 20% @1KHz
Sensitivity: Ehco signal 1000mV(-62dB) @58mm, 24Vpp
Max. Input Voltage: less than 150Vpp
Working temperature: -40~+80℃
Pressure: ≤10Kg or 1MPa
Protection Class: IP68
Housing Material: 304
Gross weight: 380g ± 5%
Wiring instructions: ‘+’ red, ‘-’ white, black: shielded cable
For more details, please contact us.
